Vacu-Maid S-3600
Technical Specs:
Motor: (2) 7.2" 2 Stage Tangential By-Pass
Voltage: 240 A.C.
Max Amps: 16.4
Max Air Watts: 12681
Airflow CFM: 229
Sealed Vacuum "H2O: 137
Filtration: Cyclonic
Sound Level: 78 db
Dirt Can: DC-1240 (Dia. 16 1/8 Ht. 40 1/4)
Capacity: 38 Qt.
Dimensions (Power Unit): Dia. 14 7/8 Ht. 20 1/4
* # of Valves: 14-20
* Max Pipe Run: 300 ft.
* Up to Total Sq. Ft.: 18,000+
*The above figures are approximate and the table is for reference only and not intended as a strict guide.
|
Vacu-maid S2600
Technical Specs:
Motor: Premier 7.2" 2 Stage Tangential By-Pass
Voltage: 120 A.C.
Max Amps: 15.8
Max Air Watts: 631
Airflow CFM: 121
Sealed Vacuum "H2O: 142
Filtration: Cyclonic
Sound Level: 60 db
Dirt Can: DC-1200 (Dia. 14 1/8 Ht. 39)
Capacity: 27 Qt.
Dimensions: Dia. 13 5/8 Ht. 12 1/2
* # of Valves: 7-11
* Max Pipe Run: 225 ft.
* Up to Total Sq. Ft.: 10,000
*The above figures are approximate and the table is for reference only and not intended as a strict guide.
|
Vacu-Maid P-125P
Technical Specs:
Motor: Premier 7.2" Tangential By-Pass
Voltage: 120 A.C.
Max Amps: 13.5
Max Air Watts: 631
Airflow CFM: 121
Sealed Vacuum "H2O: 142
Filtration: Cyclonic
Sound Level: 76 db
Dirt Can: N/A
Capacity: 27 Qt.
Dimensions: Dia. 13 5/8 Ht. 40 1/2
* # of Valves: 7-11
* Max Pipe Run: 200 ft.
* Up to Total Sq. Ft.: 9,000
*The above figures are approximate and the table is for reference only and not intended as a strict guide.
|
Vacu-Maid P-110
Technical Specs:
Motor: Premier 5.7" Tangential By-Pass
Voltage: 120 A.C.
Max Amps: 13.6
Max Air Watts: 440
Airflow CFM: 112
Sealed Vacuum "H2O: 111
Filtration: Cyclonic
Sound Level: 75 db
Dirt Can: N/A
Capacity: 25 Qt.
Dimensions: Dia. 13 5/8 Ht. 38 3/4
* # of Valves: 3-5
* Max Pipe Run: 125 ft.
* Up to Total Sq. Ft.: 5,000
*The above figures are approximate and the table is for reference only and not intended as a strict guide.
|
